Revit software is used to design 3D models for BIM, which, as you know, stands for Building Information Modeling. However, BIM is a process and Revit is a software package. Indeed, the output may appear to be similar for Revit modeling and BIM technology. Both are associated with 3D models of many design disciplines, such as MEP, structural, architectural, and so on. The confusion is understandable: The two serve the same objective, that is, developing 3D building design & modeling. If you change the length of an element, Revit maintains equal spacing among elements.You may have asked yourself: “ Are Revit and BIM different software applications that do the same job? Are they both used to produce 3D building models?“ Rebar is spaced equally across a given element.The edge of a floor or roof is related to the exterior wall so that, when you move the exterior wall, the floor or roof remains connected.If you move the wall, the door retains this relationship to the wall. A door is a fixed dimension from an adjacent partition wall.These relationships are created either automatically by the software or by you as you work. Parametric modeling refers to the relationships among all elements in a project that enable the coordination and change management that Revit provides. Parameters define the size, shape, position, material, and other information about an element in the model. These rules and relationships make changing the model easier. For example, when a roof is attached to walls, a relationship between the elements is established. These elements maintain rules and relationships to each other. Other elements-such as tags, dimensions, or other annotations-appear only in the view in which they are placed. You can think of these elements as components that exist in a building. Some elements-such as walls, windows, and beams-are 3D and appear in all views. They represent the real-world components that a designer adds to the model. Elements Revit Elements – Different stages of merging elementsĮlements are the building blocks of a 3D model. It automatically coordinates changes made anywhere-in model views, drawing sheets, schedules, sections, and plans. As you work on the building model, Revit pulls together information across all other representations of the project. In the Revit model, every drawing sheet, 2D and 3D view, and schedule is a presentation of information from the same virtual building model.
Key Revit Concepts include Modelling, Elements, Parameters & Families Modeling
